Stax SRM-D10 Portable Driver
Unit
Stax SRM-D10 Portable Driver
Silver / New
22 Saint Kilda Road
22 Saint Kilda Road
Suite 2.02
St Kilda VIC 3182
Australia

Stax


Stax SRM-D10
FEATURES
-
Compact electrostatic headphone amp/DAC
-
Battery-powered, rechargeable Li-ion built-in battery pack
-
High-resoluton Digital-to-Analog converter, supports up to DSD128
-
User selectable line-in and USB DAC
-
All-aluminum chassis
THE ULTIMATE ELECTROSTATIC DAC/AMP, CONNECT EASILY
Experience Hi-Res audio with the SRM-D10. The specially tuned DAC supports up to DSD128 (5.6MHz) and PC 384 kHz playback with an XMOS USB interface. The superior built-in amplifier is resistant to high voltage and offers a great performance. With its 3.5mm analogue input and MicroUSB digital input, the SRM-D10 makes connecting to your PC, Mac, DAP or just about any other audio player easy. The 5-pin PRO bias STAX Earspeaker output lets you connect to your favourite STAX Earspeaker and enjoy world-class audio in no time.
CARRY IT ANYWHERE, DURABILITY WITH STYLE & LISTEN FOR LONG
Now you do not need to be tied down to one spot just to listen to pure audio. The SRM-D10 is the very first electrostatic driver in the history of STAX that can be carried around. This high-quality amplifier can drive your favourite STAX Earspeakers when on-the-go. For additional durability and style, the SRM-D10 features an aluminium chassis. This case has been treated with multiple processes for a better shielding and velvety texture. Say goodbye to heaps of wires and wall outlets with the SRM-D10. The built-in rechargeable battery gives you 4.5 hours of battery life when using the analogue input and 3.5 hours of battery life when using the digital input.
AUDIO SPECIFICATIONS
FREQUENCY RESPONSE
20Hz – 40KHz (+0dB,-3dB)
GAIN
53dB (450 times)
HIGH HARMONIC DISTORTION
0.025% / 1KHz-10KHz
INPUT IMPEDANCE
10 KΩ(analog input)
MAX. OUTPUT VOLATGE
200Vr.m.s / 100Hz-10KHz
STANDARD BIAS VOLTAGE
DC 580V
SUPPLY VOLTAGE
DC 14V
VOLTAGE
100-240V/50-60HZ
CONTROLS & CONNECTIVITY
BATTERY OPERATING TIME
4.5hour(analog input) / 3.5hour(digital input)
RATED INPUT LEVEL
230mV (100V output)
MAX. INPUT LEVEL
10V (minimum volume in analog input)
RECOMMENDED OPERATING TEMPERATURE
0-35°C, <90% RH (No condensation)
SIGNAL INPUT
MicroUSB digital input, 3.5mm analog input
POWER CONSUMPTION
6.4W (USB input)、5W (analog input)
DESIGN & BUILD
DIMENSIONS
75W×32H×141Dmm
WEIGHT
450g
