Rotel T11 Digital Radio Tuner
Rotel has been producing quality tuners since the 1960s. One of the latest additions to this long-established line-up is the T11 FM/DAB+ tuner. It provides a wealth of listening options with easy access to classic analogue FM stations as well as newer DAB+ (Digital Audio Broadcasting) services.
Like the T14, T11 features the ability to easily store and recall up to 30 presets each for FM or DAB+ stations. A further useful feature common to all 14 Series products is the ability to dim the display panel and power LED to provide a comfortable visual reference in all lighting environments. With exemplary sound quality and easy to operate controls, this tuner continues in the longstanding tradition of its predecessors.
DIMENSIONS (W × H × D)
430 × 73 × 330mm
17" × 2.9" × 13"
FRONT PANEL HEIGHT
60mm (2.36")
POWER REQUIREMENTS
120V, 60Hz
POWER CONSUMPTION
10W
STANDBY POWER CONSUMPTION
<0.5W
NET WEIGHT
4.3kg (9lbs.)
BTU RATING
17 BTU/h
DAB SENSITIVITY
-80dBm
DAB TUNING RANGE
Band III (174-240MHz)
DAB AUDIO DATE RATE
224Kbps Max
DAB FREQUENCY RESPONSE
20Hz - 20kHz ±1dB
DAB ANALOG OUTPUT
2.1V at 0dBfs
DAB ANTENNA INPUT
75Ω F Connector
