Reed Muse 1C Turntable
Variant
Reed Muse 1C Turntable
Belt Drive / Black
22 Saint Kilda Road
22 Saint Kilda Road
Suite 2.02
St Kilda VIC 3182
Australia
Country of origin: Lithuania
Muse 1C
Reed Muse 1C is our first step into traditional design, middle range turntable market, while keeping our commitment to highest quality and representing our passion for innovations.
Shaped with traditional 70ies design elements in mind, Reed Muse 1C features robust, stable and resonance-free wooden body, however a lot of Muse 1C technologies, including main bearing and drive traction control, are inherited from our flagship Muse 3C. Traditionally, Muse 1C can play 33 and 45 RPM records, however if you have 16 RPM or 78 RPM LPs, you will find these operation modes in Muse 1C as well. For your convenience, 78 RPM speed can be manually adjusted in range of 70-85 RPM. Muse 1C also features electronic inclinometer (electronic level dedicated to measure turntable slope/tilt angle), which allows user to achieve perfect horizontal alignment without using additional tools.
Muse 1C can be fitted with one center or off-center mount tonearm with effective length ranging from 9.5 to 12 inch.
SPECIFICATIONS
Color | Moonlit Black, Karelian birch |
Drive | Friction, belt, two direct current (DC) motors |
Speed | 16, 33, 45, 78 rpm; 78 rpm can be manually adjusted |
Speed stabilizing system | Quartz-based phase locked loop (PLL) |
Max deviation of average speed | +/- 0.05 % |
Supply voltage | DC 10-14V, via 100 – 240V AC adapter or Reed Source 12V |
Inclinometer accuracy range | 1mm per meter |
Packaging dimensions (L x W x H) | 650 x 520 x 350 mm |
Product weight netto(unpacked) | 15 kg |
Product weight brutto(packed) | 20 kg |
Tonearms | single, center or off-center mount; effective length from 9.5 to 12 inch |
Color
Moonlit Black, Karelian birch
Drive
Friction, belt, two direct current (DC) motors
Speed
16, 33, 45, 78 rpm; 78 rpm can be manually adjusted
Speed stabilizing system
Quartz-based phase locked loop (PLL)
Max deviation of average speed
+/- 0.05 %
Supply voltage
DC 10-14V, via 100 – 240V AC adapter or Reed Source 12V
Inclinometer accuracy range
1mm per meter
Packaging dimensions (L x W x H)
650 x 520 x 350 mm
Product weight netto(unpacked)
15 kg
Product weight brutto(packed)
20 kg
Tonearms
single, center or off-center mount; effective length from 9.5 to 12 inch
