JBL MA510 5.2-Channel Net AV Receiver
JBL MA510 5.2-Channel Net AV Receiver
Black
22 Saint Kilda Road
22 Saint Kilda Road
Suite 2.02
St Kilda VIC 3182
Australia

JBL

MA510
5.2-channel 8K AV Receiver
Bring both music and movies to life with true high fidelity.
The JBL MA510 is an AV Receiver that delivers spectacular realism with 8K HDMI specifications for a supreme home cinema experience. Seamlessly integrate your smart TV or projector with 4 HDMI inputs and 1 output, plus eARC. With native 5-channel decoding of Dolby and DTS formats, the MA510 can deliver incredible cinema experiences. It is designed with a passion for music and movies, bringing both to life with true high fidelity. Additional music content can be accessed via Bluetooth and network streaming. The MA510 features five channels of low noise Class D amplification for real world power to all channels.
Features

Stunning audio and video performance
5.2-channel AV receiver that delivers stunning realism with the latest 8K video for the ultimate home cinema experience

Intuitive setup with a minimalist modern design
Seamless integration with smart TVs, gaming consoles, streaming, cable boxes and more with 4 HDMI inputs and 1 output, plus eARC

High-performance immersive surround sound
Native 5-channel decoding of Dolby and DTS formats.
Bring both music and movies to life with true high fidelity
Stream music wirelessly via Bluetooth and network streaming (Apple Airplay 2, Google Chromecast, Roon Ready)
On-Screen Setup and Operation
On-screen display for easy system setup and operation (via HDMI).
Bluetooth and network streaming
Stream music wirelessly via Bluetooth and network streaming (Apple Airplay 2, Google Chromecast)
Powerful amplification
Five channels of low noise Class D amplification for real world power to all channels.
EZ Set EQ
EZ Set EQ provides easy-to-use room equalization for optimized sound quality.
What's in the box?
- 1x IR Remote
- 2x AAA batteries
- 1x Bluetooth antenna
- 2x Wi-Fi antenna
- 1x Power Cord
- 1x Quick-Start Guide
- 1x Safety Sheet
Videos
HDMI eARC | Yes |
HDMI Audio Return Channel | Yes |
8K HDMI input connectors (HDMI 2.1, HDCP 2.3 up to 8K/60Hz, 4K/120Hz) | 3 |
HDMI 2.1 enhanced gaming features | Gaming-VRR, ALLM, QFT, HFR (4K@120Hz) |
HDR 10+, Dolby Vision | Yes , Yes |
File format | MP3 / MPEG-4 AAC |
Pure Analog | Yes |
EZ Set EQ | Yes |
Digital signal processing | up to 24-bit/192kHz |
Mains voltage | 110 – 240V, 50–60Hz |
Max. power consumption | 300W |
Standby power consumption | <0.5W |
AUDIO SPECIFICATIONS |
|
Channels | 5.2 |
FTC Rated Output Power (20Hz– 20kHz, 2 channels driven, 1% THD max, 8Ω) | 75W |
Rated Power @ 8Ω (20Hz – 20kHz, 2 channels driven, 0.5% THD max) | 75 W RMS |
Rated Power @ 4Ω (20Hz – 20kHz, 2 channels driven, 0.5% THD max) | 100 W RMS |
Dimensions incl. feet and speaker terminals (H x W x D) | 5.3" x 17.0" x 15.6" (135.0mm x 432.0mm x 396.4mm) |
Weight | 16.4lb (7.4kg) |
Control and Connection Specifications |
|
HDMI Input/Output | 4/ 1 |
Wi-Fi | Yes (2.4/5GHz) |
Bluetooth receiver | Yes (v4.1, Low Energy) |
Bluetooth transmit | Yes |
Digital Audio Input | 1 Coax, 1 Optical, 1 USB |
Stereo analog input | Yes (v4.1, Low Energy)2 single-ended RCA |
Pre-Out (single ended RCA) | Subwoofer 1, Subwoofer 2 |
Ethernet | RJ45 Gigabit, WiFi Onboard |
