JBL Classic SA550 Streaming Integrated Amplifier with Bluetooth
JBL Classic SA550 Streaming Integrated Amplifier with Bluetooth
Silver/Walnut
22 Saint Kilda Road
22 Saint Kilda Road
Suite 2.02
St Kilda VIC 3182
Australia
Country of origin: USA
SA550 Classic
Integrated Amplifier with Bluetooth
The JBL SA550 Classic is inspired by the classic JBL SA600 amplifier from the 1960’s, with retro styling and walnut veneer side panels to match JBL Classic and Studio Monitor loudspeakers on the outside. On the inside, the JBL SA550 is a music system for today using an advanced amplifier topology with high power output, inventive efficiency, and fine noise control for captivating musicality and effortless power. Straight out of the box, pair your smart phone or tablet to the SA550 Classic with Bluetooth for instant high-quality music from all your music services and libraries that you listen to everyday. The JBL SA550 Classic includes the latest Bluetooth AptX®Adaptive technology for hi-res audio over Bluetooth and low latency to ensure audio is in sync with video. All digital audio is rendered using a reference high resolution DAC with time domain jitter elimination for perfect sound, every time.
Features
- JBL Classic Design with Natural Walnut
- Bluetooth with aptX™Adaptive Technology
- Class G amplification for exquisite musicality
- Hi-Res Digital Audio Inputs
- MM phono stage ready for Turntables
- 150W per channel powers all JBL Classic and Studio Monitor loudspeakers with ease.
Continous power output both channels driven (0.5% THD):
- 90W into 8Ω x 2
- 150W into 4Ω x 2
- Harmonic distortion, 80% power, 8Ω at 1kHz: 0.002%
Phono moving magnet input:
- Input sensitivity at 1kHz: 5mV
- Input impedance: 47kΩ + 100pF
- Frequency response (ref. RIAA curve): 20Hz - 20kHz ±1dB
- Signal/Noise ratio (A-wtd) 50W, ref. 5mV input: 80dB
- Overload margin, ref. 5mV at 1kHzOverload margin, ref. 5mV at 1kHz
Line inputs:
- Nominal sensitivity: 1V
- Input impedance: 10kΩ
- Maximum input: 6Vrms
- Frequency response: 20Hz - 20kHz ±0.2dB
- Signal/Noise ratio (A-wtd) 50W, ref. 1V input: 106dB
Digital inputs:
- Supported Bit depth: 16 bit - 24 bitSupported Bit depth: 16 bit - 24 bit
- Supported sample rates (Optical)(kHz): 32, 44.1, 48, 88.2, 96
- Supported sample rates (Coaxial)(kHz): 32, 44.1, 48, 88.2, 96, 176.4, 192
- Frequency response: 20Hz - 20kHz ±0.05dB
- Signal/Noise ratio (A-wtd) 50W, ref. 1V input: 115dB
Mains Voltage:
- 110–120V or 220–240V, 50–60Hz
- Maximum Power Consumption: 500W
Product Dimensions (W x H x D, including feet, control knob, mand speaker terminals)
- 449 x 114 x 327mm
Product Weight:
- 12kg
Shipping Weight:
- 14kg
Warranty:
- 5 Years
