Bel Canto e.One REF501S Stereo Power Amplifier

Bel Canto

Bel Canto e.One REF501S Stereo Power Amplifier

$4,350.00

Includes GST. 🚚 Free shipping on orders over $100 Australia wide at checkout.

Faceplate Colour:

Faceplate Colour
Quantity:
Pickup available at 22 Saint Kilda Road Usually ready in 2-4 days

Bel Canto e.One REF501S Stereo Power Amplifier

Black

22 Saint Kilda Road

Pickup available, usually ready in 2-4 days

22 Saint Kilda Road
Suite 2.02
St Kilda VIC 3182
Australia

0395250022
We accept:
American Express Apple Pay Google Pay Mastercard PayPal Shop Pay Union Pay Visa Zip

Country of origin: USA

Ask Geoff

If the product is not able to be added to your cart for one or more of these reasons:

  1. The supplier has a policy that prevents us from doing so.
  2. There are delays in supply, and I would prefer to make you aware of lead times;
  3. This is a bespoke item and I don't want you to pay in full and wait a long time for it to be made and shipped,
  4. I would like to discuss the synergy of the product matching with your system
  5. Due to fluctuating shipping and currency effects, the product may have come down in price. I can offer you a market price.

Please use this resource and contact me using the following form or call me.

Your Javascript is disabled

REF501S Stereo Amplifier

The REF501S stereo amplifier, solidly built all-aluminum compact chassis, delivers dynamic, accurate hi resolution sound at 250 Watts with incredible speed and control.

  • Max Power Output 250W @1% THD per Channel
  • Minimum Load: 2 ohms per Channel
  • Peak Output Current: 17.5 Amps per Channel
  • Balanced Input Impedance: 95 Kohms
  • Voltage Gain 27dB

REF501S Stereo Amplifier Features

Impedance Optimized Input Stage uses selected precision resistors in a balanced high Common Mode Rejection, low output impedance driver that is critical to the amplifier's performance, ensuring that the refined dynamic qualities of the recording are preserved.

DC Signal Path

The REF501S is DC coupled with no coupling capacitor in the signal path. This optimizes the audio signal quality and maximizes both micro and macro dynamic performance. The amplifier will protect itself and your speakers if excess DC is detected with very fast shut-off.

Why Class D?

Well-designed Class D switching supplies generally sound more open through the midrange with better Bass control. Note that 250W is 23.9dBw which means that it will drive an 85dB speaker to 108dB with 111dB peaks, theoretically. In a large room with the volume control 10dB below max we’re measuring about 25W of continuous power. This is loud! Most power concerns are more about control rather than how much real power is delivered. This gives further advantage to Class D and switching power supplies as their efficiency is high even at lower power outputs helping them sound ‘bigger’.

WBT NextGen Speaker Connectors

The WBT NextGen connectors provide the best possible connection from the amplifier to the speaker cables. We choose them because they impart minimal sonic signature to the sound, remaining open and grain-free up throughout the audio frequency band.
